A Set of Mirae Series Pick-and-place Nozzle Type A, B, C, D, E, P are suitable for your High-Speed Mounter MX100 / MX400 / MPS-1010 / MPS-1030:

SMT Nozzle Type A - PART NO.21003-61000-005, external diameter 1.0 mm, inner diameter 0.5 mm
SMT Nozzle Type B - PART NO.21003-62000-105, external diameter 1.2 mm, inner diameter 0.7 mm
SMT Nozzle Type C - PART NO.21003-63000-005, external diameter 2.0 mm, inner diameter 1.2 mm
SMT Nozzle Type D - PART NO.21003-64000-005, external diameter 3.0 mm, inner diameter 2.0 mm
SMT Nozzle Type E - PART NO.21003-65000-005, external diameter 6.0 mm, inner diameter 4.5 mm

- The Mirae Pick-and-place Nozzle mouth part (Type A, B, C, D, E) is made of diamond and ceramic, which is durable and not whitish. (- The Mirae Nozzle mouth part (Type E) is made of antistatic rubber and plastic materials, which has strong toughness and wear resistance.)
- The Mirae Nozzle (Type A, B, C, D, E, P) reflector is made of green plastic steel, which can be used interchangeably with the original nozzle without any error.
- The Mirae SMT Nozzle (Type A, B, C, D, E, P) Ontology is made of high-quality imported steel after high temperature treatment, which is durable.
- The Mirae Nozzle (Type A, B, C, D, E, P) positioning cover is processed by wire cutting, with smooth matching and not easy to wear.
- Mirae (Type A, B, C, D, E, P) Nozzle Seat - Every detail is carefully polished from inside to outside.
- The Mirae nozzle (Type A, B, C, D, E, P) is suitable for the installation of components such as suction resistance-capacitance, switch button, lamp bead, diode, USB interface, lens, camera, etc.
